T300 Mobile

Portable all payment options & high performance

OVERVIEW

T300 Mobile Terminal is a powerful payment device can handle various payment transactions like credit card, debit card, EMV, loyalty, installment, contactless payment and QR code payment in a single terminal.

Core Features

• ARM® Cortex® 500MHz secure processor
• 2.8” LCD color large display
• Support EMV Chip & PIN (PCI PTS 4.x certification)
• Support MagStripe and contactless payment
• Support QR base application
• USB & RS232 communication interface
• Fast thermal printer
• Large capacity battery
• Wide keypad

Optional

• Build-in contactless reader
• Camera for 1D or QR decode
• Upgrade to resistive touch screen
• Dual SIM support
• GPRS or 3G WCDMA/GPRS communication, WIFI/Bluetooth® V4.x

One-stop Solutions All in T300 Mobile

Specifications

Processor

ARM® Cortex® 500MHz secure processor

Display

2.8″ LCD color display, 320 x 240
Resistive touch screen & signature pad (optional)

Reader

Magnetic Track 1/2/3
EMV
NFC Contactless (optional)
QR code payment (optional)

Memory

64MB RAM
128/512MB Flash

Keys

20

Camera

Optional

Card Slots

SAM x max. 2
SIM x 2 (optional)

Thermal Printer

Printing speed: 30lines/sec
Paper roll: 40mm diameter

Communication interface

GPRS/3G/WIFI
Optional: Bluetooth®

Peripheral

RS232 x 1
USB OTG x 1

Audio synthesizer

Optional

Battery

Min. 2600mAh rechargeable battery

Power supply

DC 5V 1A (For charging only)

Certifications

PCI PTS
Visa PayWave
American Express ExpressPay
CUP QuickPass
JCB J/Speedy
TQM

EMV L1 & L2
MasterCard Contactless
SRED
QPBOC
FCC/CE/CCC

Operating temperature

0 – 45ºC

Storage temperature

-20 – 70ºC

Operating humidity

0 – 85% non-condense

Dimensions & weight

165 (L) x 80 (W) x 57 (H) mm
340g (with battery)

*Specifications is subject to change without prior notice.

Standpole Peripheral

This standpole is special designated for T300 Countertop Terminal which can move more than 270˚ tilt and swivel to fit for end-user needs.
